300KG Gas Fired Stationary Copper Melting Furnace

300KG Gas Fired Stationary Copper Melting Furnace

The WDL-RG-300F Gas Fired Stationary Copper Melting Furnace is a high-efficiency, energy-saving industrial furnace designed specifically for melting copper and copper alloys. Engineered for fast melting, stable temperature control, and long service life, this gas-fired crucible melting furnace is widely used in copper foundries, metal casting workshops, and precision manufacturing industries.

1. Application and Advantages

The WDL-RG-300F copper melting furnace is designed to achieve superior melting performance under stable working conditions. With its advanced natural gas combustion system and Siemens PLC+HMI control, it ensures precise temperature management, high thermal efficiency, and reduced fuel consumption. This stationary copper furnace operates continuously and efficiently, providing consistent melting quality and minimized maintenance downtime.

2. Technical Parameters

3. Advanced Structural Design

• Furnace Shell: The shell is made of high-strength welded and cast steel plates, providing excellent rigidity and stability under high temperatures. The pressure ring is crafted from cast iron to ensure strong mechanical support.

• Furnace Lining: The melting pool uses a one-time forming castable material with a compressive strength above 140MPa at 110℃ and a linear change rate of just 0.1%. The thermal insulation layer is built using premium aluminum silicate fiber board and lightweight firebricks, ensuring exceptional heat retention and minimal energy loss.

• Graphite Crucible: A Golden Elephant brand graphite crucible is included, offering high thermal conductivity, resistance to oxidation, and extended operational life.

4. Intelligent Gas Burning System

The pipeline burning system integrates automatic ignition, flame detection, and dual-stage flame control (big/small flame) to optimize combustion efficiency. The system automatically adjusts based on temperature thresholds, maintaining a stable melting environment.

Main Components of the Gas System:

• Honeywell – Flame detector, solenoid valve, ignition controller, and electric actuator

• Fiorentin – Gas pressure reducing valve

• CKD (Japan) – Ignition solenoid valve

• Astechnic (China) – High-performance gas burner

• Taiwan – Cooling fan

• Japan – Proportional valve

This integrated system ensures safe, efficient, and precise combustion, meeting global industrial standards for gas-fired furnaces.

5. Supply Scope and Features

Each WDL-RG-300F gas-fired crucible furnace package includes:

• Furnace body – 1 unit

• Pipeline burning system – 1 set

• Electrical control system and cabinet – 1 set

• Automatic temperature controller (Taiwan) – 1 pc

• Thermocouples – 2 pcs (1 spare)

• Graphite crucible and fireproof retaining ring

• Complete user manual

6. Key Benefits

• Rapid copper melting (up to 150 kg/hour)

• Stable temperature control (±15℃) with PLC automation

• Low fuel consumption and high combustion efficiency

• Long-lasting refractory lining and crucible

• Safe operation with automatic flame monitoring and shutdown protection

The WDL-RG-300F Gas Fired Copper Melting Furnace combines durability, intelligence, and efficiency—making it the ideal solution for copper alloy foundries, brass casting, and non-ferrous metal processing. With its Siemens control system, Honeywell gas components, and energy-saving insulation design, it delivers precise control, reliable performance, and reduced operating costs.
